The TH+ Turnable Corner system offers unmatched design flexibility by allowing individual glass panels to glide effortlessly around corners and park out of sight. Ideal for opening up facades and maximising usable space, this system delivers both thermal performance and aesthetic purity.
Innovative turnable corner configuration for total opening flexibility
Roller-based movement system for effortless manual operation
Panel sizes up to 6 m², supporting up to 250 kg per panel
Slim 22 mm vertical profile for near-invisible joins
Custom options: pocket integration, stacking, open angles
High thermal insulation with 32–44 mm glass thickness
Designed for complete architectural freedom
The Vitrocsa TH+ Turnable Corner system transforms interior and exterior spaces by eliminating traditional corner barriers. By sliding each panel independently and allowing full rotation, the system clears the entire opening—perfect for expansive views and seamless transitions.
Its roller principle ensures smooth, quiet operation while advanced aluminium profiles provide thermal insulation and structural strength. The system supports large-format glazing with concealed tracks and high-spec finishes for a minimalist aesthetic.
Whether you need a mono-rail or bi-rail layout, with or without pocket integration, the TH+ Turnable Corner adapts to your design needs. The marine-grade materials also make it ideal for coastal or high-exposure environments.
Each glass panel in the system is fitted with rollers that follow an overhead and floor-guided track. As panels reach a corner or end-point, they can be manually turned and slid into a perpendicular stacking position, clearing the full opening.
The result is a flexible façade system that offers true transparency when open, and outstanding thermal and acoustic performance when closed. The system can be tailored to project needs with optional pocket integration and locking mechanisms.
Thermally broken corner-opening system with fully retractable glass panels
Supports insulated glazing from 32 to 44 mm for optimal thermal and acoustic performance.
Each panel can reach up to 6 m² in surface area and carry up to 250 kg in weight.
Minimal 22 mm vertical connection for sleek, uninterrupted sightlines.
Panels pivot and slide around corners, stacking away to fully open façades or walls.
Compatible with mono-rail and bi-rail systems, integrated pocket options, and open angle layouts.
Equipped with thermal break profiles and insulation-grade glazing for energy efficiency.
Standard 25-micron natural anodised aluminium with optional powder coating or anodised colour finishes.
Designed with corrosion-resistant components and smooth tracks for longevity in exposed or coastal settings.
We take pride in delivering exceptional glazing solutions and outstanding customer service. Here’s what some of our happy clients have to say about working with Minimal Frame Projects.
Explore how this space-saving corner solution redefines fluidity and elegance across high-end residential and commercial projects.
