Precision-Engineered Glazing Systems for Commercial Architecture

Explore our range of advanced commercial glazing solutions — from aluminium curtain walling and fire-rated façades to high-performance entrance doors and roof glazing systems. Engineered for modern architectural demands, our systems deliver exceptional thermal insulation, safety compliance, and elegant aesthetics for offices, retail units, public buildings, and more. All products are backed by industry certifications and tailored for seamless integration across your project’s envelope.

Aluminium doors series S2es-d

High-security aluminium doors with advanced protection against forced entry (up to RC5), ballistic threats (up to FB7-NS), and blasts (up to 500 kg of explosives), without compromising on design flexibility or ease of use.

Min. face width	91 mm	Uf value of frame (≥)	1.5 W/(m²·K)
Max. glass/panel thickness	62 mm	Max. vent width	1300 mm
Max. vent height	2500 mm	Max. sound reduction index Rwp	44 dB(A)
Air permeability	Class 4	Watertightness	Class 7A, Class 9A
Burglar resistance	Up to RC 2	Wind load resistance	Class C3 / B3, Class C5 / B5
CE marking	Yes	Total basic depth	80 mm
Width of vent frame	80 mm	Max. vent weight	160 kg
Min.-max. vent height	…2500 mm	Min.-max. vent width	…1300 mm
Outer frame face width	51 mm	Vent frame face width	40 mm
Max. face width of mullion	250 mm	Min.-max. face width of mullion	76…250 mm
Max. face width of meeting stile	163 mm	Min.-max. face width of meeting stile	148…163 mm
Min.-max. glass/panel thickness	21…62 mm	Barrier-free (≤) 20 mm	Yes
Zero-level threshold	Yes	Area of application	External use, Residential projects, Commercial projects, Healthcare
Shear bond	Yes	Concealed fittings system	Yes
Surface finishes	Powder, Anodised, Paint	Glass composition	Triple glazing
Operating forces	Class 2	Barrier-free operating forces in accordance with DIN 18040	Yes
Opening type: manual, inward-opening	Turn/tilt, Side-hung, Bottom-hung, Double-vent turn/tilt / side-hung, Double-vent side-hung / side-hung, Tilt-before-turn	Opening angle	180 °
Mechanical strength	Class 4	Proof of durability	Class 3
Corrosion protection class for fittings	Class 5	Drainage levels	3
Integrated sun shading	Yes	Schüco sun shading possible	Yes
Security glazing	Yes	Electronic monitoring	Yes
Colour-independent	Yes

Uf value of frame (≥)	1.4 W/(m²·K)	Max. height	3000 mm
Max. width	1400 mm	Max. glass/panel thickness	53 mm
Max. vent weight	200 kg	Area of application	Residential projects, Commercial projects
Surface finishes	RAL, Anodised	Air permeability	Class 4
Watertightness	E 750	Wind load resistance	Class C3 / B3
Burglar resistance	Up to RC3	Impact resistance	Class 1
Min.-max. height	0…3000 mm	Min.-max. width	0…1400 mm
Min. face width	151 mm	Min.-max. glass/panel thickness	13…53 mm
Barrier-free (≤) 20 mm	Yes	Zero-level threshold	Yes
Thick door leaf	75 mm	Type of design	Single-vent, Double-vent, Single-vent and side section, Double-vent and side section, Single-vent with toplight, Double-vent with toplight, Single-vent with toplight and side section, Double-vent with toplight and side section, Single-vent with side section, right, Single-vent with side section, left, Single-vent with side section, right and left, Single-vent with side section and toplight, Double-vent with side section, right, Double-vent with side section, left, Double-vent with side section, right and left, For use in façade
Vent option	All around, Sill rail profile, Adjustable sill, Flush-fitted, Inward opening, Outward-opening, Insert panel infill, Door infill, leaf enclosing on one side, Door infill, leaf-enclosing on two sides	Infill type	Insert panel infill, Door infill, leaf enclosing on one side, Door infill, leaf-enclosing on two sides
Door threshold	Aluminium, Automatic door gasket, Flat door threshold, Easy-access door threshold	Special applications	Anti-finger-trap door, Sheet metal clad door, Opposed opening door, Swing door, Flush-fitted
Fitting material	Aluminium, Stainless steel	Concealed fittings system	Yes
Neutral-colour fitting	Yes	Fittings installation	Surface-mounted door hinge, Concealed door hinge, Barrel hinge
Electric strikes	Yes	With panic function	Yes
Finger-trap protection	Yes	Opening type	Side-hung, Inward and outward, Single and double-vent
DIN direction	DIN LH / RH	Door swing	Flush-fitted
Mechanical strength	Class 3	Proof of durability	Class 7, Class 8
Behaviour between different climates	Class 2(d),2(e)	Max. sound reduction index Rwp	42 dB(A)
Top / bottom door closers	Yes	Door closer type	Top closers
Certificates	RAL quality mark, cradle2cradle SILVER	CE marking	Yes

Min. face width	127 mm	Max. height	3284 mm
Max. width	3390 mm	Max. weight	350 kg
Fire protection	F30, T30, EI30	Smoke protection	SA, S200, RS1, RS2
Burglar resistance	Up to RC 2	Basic protection against vandalism	No
Suitable for safety barrier loading	Yes	Max. sound reduction index Rwp	43 dB(A)
Min.-max. width	598…3390 mm	Min.-max. height	1732…3284 mm
Min. clear opening dimension (w x h)	456 x 1648 mm	Max. clear opening dimension (w x h)	3022 x 3100 mm
Max. glass/panel thickness	53 mm	Max. glass size (w x h)	1500 x 3000 mm
Area of application	Internal use, Commercial projects	Type of design	Single-vent, Double-vent, Single-vent and side section, Double-vent and side section, Single-vent with toplight, Double-vent with toplight, Single-vent with toplight and side section, Double-vent with toplight and side section, Single-vent with side section, right, Single-vent with side section, left, Single-vent with side section, right and left, Single-vent with side section and toplight, Double-vent with side section, right, Double-vent with side section, left, Double-vent with side section, right and left, For use in glazing
Use	Door, Fixed glazing	Special applications	Anti-finger-trap door, Flush-fitted
Emergency exit door	Yes	Concealed fittings system	Yes
Direction of opening	Side-hung, Inward and outward, Single and double-vent	Mechanical strength	DIN EN 1192, Class 4
Proof of durability	200,000 cycles in accordance with DIN EN 12400, 1,000,000 cycles in accordance with DIN EN 12400	Security system	Yes
Certificates	cradle2cradle SILVER	Standards	DIN 4102, DIN EN 1192, DIN EN 1627, DIN 18095, EN 1634, EN 1364, EN 12210, EN 12208, EN 12207, 200,000 cycles in accordance with DIN EN 12400, 1,000,000 cycles in accordance with DIN EN 12400, EN 13501-2, DIN EN 14351-1, EN 16034
